Cones, spheres and hemispheres trip up Class 9 students for a simple reason: the formulas look alike, and it is easy to use the height where the slant height belongs, or to forget the flat base of a bowl. This post covers what the 2026-27 syllabus asks for, works through one example for each solid with checked numbers, explains where the formulas come from, and ends with a short practice routine.
What does the Class 9 syllabus cover in surface area and volume?
The CBSE Mathematics curriculum for Class IX (2026-27) has been redesigned around the new NCERT textbook. Its Mensuration unit, which carries 14 of the 80 marks together with Area and Perimeter, asks you to compute the surface area and volume of cuboids, cylinders, cones, pyramids and spheres. The textbook chapter is Chapter 14, Math of Space: Surface Area and Volume, in Ganita Manjari, Part II. If you are using an older guide, note that the chapter now starts with cuboids and cylinders and includes pyramids. Check the curriculum on the CBSE site for your own year, since it changes.
How do you find the surface area and volume of a cone?
A right circular cone has three measurements: base radius r, height h and slant height l. They form a right triangle, so l² = h² + r².
Curved surface area (CSA) = πrl
Total surface area (TSA) = πrl + πr² = πr(l + r)
Volume = (1/3)πr²h
Example. A cone has radius 7 cm and height 24 cm. Take π = 22/7.
Slant height: l² = 24² + 7² = 576 + 49 = 625, so l = 25 cm.
CSA = (22/7) × 7 × 25 = 550 cm².
TSA = 550 + (22/7) × 7 × 7 = 550 + 154 = 704 cm².
Volume = (1/3) × (22/7) × 7 × 7 × 24 = (1/3) × 154 × 24 = 1232 cm³.
Notice that the slant height goes in the surface area and the vertical height goes in the volume. That single swap is the most common error in this chapter.
Why is a cone's volume one third of a cylinder's?
NCERT explains the curved surface by unrolling the cone into a sector and cutting it into thin triangles of height l, which gives (1/2) × 2πr × l = πrl. For the volume, the full reason needs calculus, so the book suggests an experiment: fill a paper cone with salt and pour it into a cylinder with the same base and height. It takes three cones to fill the cylinder. The same one-third rule works for any pyramid: volume = (1/3) × base area × height.
How do you work with spheres and hemispheres?
Archimedes showed that a sphere's surface equals the curved surface of the cylinder that fits tightly around it, which is 2πr × 2r = 4πr². He also found the volume, (4/3)πr³.
Example. A ball has radius 10.5 cm.
Surface area = 4 × (22/7) × 10.5 × 10.5 = 4 × 346.5 = 1386 cm².
Volume = (4/3) × (22/7) × 10.5³ = (4/3) × 3638.25 = 4851 cm³.
A hemisphere is half a sphere, but it also has a flat circular face.
CSA = 2πr²
TSA = 2πr² + πr² = 3πr²
Volume = (2/3)πr³
Example. A hemispherical bowl has radius 21 cm.
Inside surface to be polished (curved only) = 2 × (22/7) × 21 × 21 = 2772 cm².
A solid hemisphere of the same size has TSA = 3 × (22/7) × 441 = 4158 cm².
Capacity = (2/3) × (22/7) × 21³ = (2/3) × 29106 = 19404 cm³. Since 1000 cm³ = 1 litre, the bowl holds about 19.4 litres.
One nice check from the textbook's exercises: a sphere's volume is two thirds of the volume of the smallest cylinder that encloses it. For r = 21 cm, the cylinder has volume (22/7) × 441 × 42 = 58212 cm³, and two thirds of that is 38808 cm³, which is exactly twice the hemisphere's 19404 cm³.
What mistakes cost marks in this chapter?
Height for slant height. Use l in πrl, h in (1/3)πr²h.
Diameter for radius. Halve the diameter before you square or cube it.
Forgetting the base. A solid hemisphere's TSA is 3πr², not 2πr². A bowl or an open tent has no base to add.
Squared versus cubed units. Areas in cm², volumes in cm³. Convert to litres only at the end.
Scaling. If the radius doubles, surface area becomes 4 times and volume 8 times. The textbook asks you to show that a 10% increase in radius raises volume by about 33.1%, because 1.1³ = 1.331.
The half-full cone. Fill an upside-down conical cup to half its depth and the water is a smaller cone with half the radius and half the height, so it holds (1/2)³ = 1/8 of the cup, not half.
A practice routine for surface area and volume
Research on how maths is practised supports two habits here. In a study of 126 seventh-grade students, Rohrer and colleagues found that mixing problem types in practice, rather than doing one type at a time, gave higher scores on tests one day and 30 days later. A large review of study methods by Dunlosky and colleagues rated practice testing and spaced practice as the most useful, and rereading as low in usefulness.
Day 1: Write the five formula sets from memory, then check them against the chapter summary.
Day 2: Do six mixed problems: two cones, two spheres, two hemispheres, shuffled. Before each one, write which measurement goes where.
Day 4: Do the guesstimate problems at the end of the chapter, such as the golgappa example. Guess first, then calculate.
Day 7: Without notes, redo any problem you got wrong.
If the formulas still feel like a list to memorise, see them move. The Fermi Simulation Lab has interactive simulations for ideas that are easier to see than to read. Next year you will combine these solids, which our guide to surface areas and volumes in Class 10 covers.
Tonight, take one cone and one hemisphere problem from Exercise Sets 14.3 and 14.4 and solve them without looking at the formulas.
