You know the formula. You know there is a right-hand rule. Then the answer key says the force points into the page and you said out of it. Direction questions on magnetic force are among the easiest marks to lose, because one slip in the cross product flips the answer. This post explains where those slips come from, gives you one method to use every time and works through examples for a moving electron and a current-carrying wire.
What does the formula say?
The NCERT Class 12 chapter Moving Charges and Magnetism writes the Lorentz force as F = q[E + v × B]. For the magnetic part it notes three features: the force on a negative charge is opposite to that on a positive charge; it is zero when v is parallel or antiparallel to B; and it is perpendicular to both v and B, with its direction given by the right-hand rule for the cross product. Its magnitude is qvB sin θ, where θ is the angle between v and B.
The chapter also points out a consequence that many students forget: because the force is always perpendicular to the velocity, it does no work and cannot change the particle's speed, only its direction.
Why are right-hand-rule answers so often wrong?
Scaife and Heckler (2010) ran five studies on how students judge the direction of the magnetic force on a charged particle. Some students believed charges are attracted to magnetic poles, an idea that persisted after teaching. Even among students who knew the right idea, the responses showed "persistent and largely random sign errors". The authors traced these to confusion about the direction of the field, the execution and choice of right-hand rule, and not recognising that the cross product is not commutative: v × B points opposite to B × v.
On the broader Conceptual Survey of Electricity and Magnetism, given to more than 5000 introductory students, average post-test scores were 47% in calculus-based courses and 44% in algebra-based ones. Electricity and magnetism are hard for almost everyone, so a careful method is worth the effort.
One method for the direction
Find B correctly first. Outside a magnet, field lines run from north to south. For a wire or coil, use the right-hand thumb rule for the field before you think about force.
Write the vectors in order: v, then B (or L, then B for a wire). Never swap them.
Use one rule and only one. Point the fingers of your right hand along v, curl them towards B through the smaller angle, and your thumb gives v × B. Some students prefer Fleming's left-hand rule for wires. Choose one and practise only that.
Fix the sign for the charge. For a negative charge such as an electron, reverse the direction.
Check with unit vectors. x̂ × ŷ = ẑ, ŷ × ẑ = x̂, ẑ × x̂ = ŷ, and each reversed pair gives a minus sign.
Worked example 1: an electron in a uniform field
An electron moves at 2.0 × 10⁶ m/s along +x through a uniform field of 0.010 T along +y. Find the force and the radius of its path. (Take e = 1.6 × 10⁻¹⁹ C and mₑ = 9.11 × 10⁻³¹ kg.)
Direction. v × B is along x̂ × ŷ = +ẑ. The charge is negative, so the force is along −z.
Magnitude. F = evB = (1.6 × 10⁻¹⁹)(2.0 × 10⁶)(0.010) = 3.2 × 10⁻¹⁵ N.
Radius. The force provides the centripetal force, so r = mv/(eB) = (9.11 × 10⁻³¹ × 2.0 × 10⁶) / (1.6 × 10⁻¹⁹ × 0.010) ≈ 1.1 × 10⁻³ m, about 1.1 mm.
Period. T = 2πm/(eB) ≈ 3.6 × 10⁻⁹ s. It does not depend on speed, a fact JEE questions like to test.
Worked example 2: a wire in a field
A straight wire 0.20 m long carries 3.0 A along +x in a uniform field of 0.40 T along +z. Find the force on it.
F = IL × B. The magnitude is ILB = 3.0 × 0.20 × 0.40 = 0.24 N. The direction is x̂ × ẑ = −ŷ, so the force is 0.24 N along −y. If you wrote +y, you computed B × L, the most common slip.
What other mistakes should you watch for?
Using sin θ with the wrong angle. θ is the angle between v and B, not between v and the force.
Expecting the speed to change. A magnetic field alone changes direction, not speed. If your answer has the particle speeding up, an electric field must be involved or the working is wrong.
Ignoring the parallel component. When v is at an angle to B, only the perpendicular component gives circular motion; the parallel component carries on unchanged, so the path is a helix.
Mixing up rules. The thumb rule for the field around a wire and the rule for the force are different. Our post on common vector errors in JEE physics covers cross products in more depth.
Direction problems are easier to get right once you have watched them happen. The Fermi Simulation Lab has interactive simulations for ideas that are easier to see than read, so you can watch how a charge's path changes when you flip the field. For reading field-line diagrams, see our guide to electric and magnetic field lines.
A practice routine for this chapter
Ten direction-only questions a day for a week, written as unit-vector products before using your hand.
For each, state the answer for a proton and for an electron.
Two radius and period calculations every other day.
At the end of the week, a mixed set that includes wires, loops and charged particles.
This evening, do five direction questions using only unit vectors, then check each one with your right hand.
