Put a drop of pond water or a cheek cell under a school microscope without stain and you see very little. The cells are nearly transparent. Staining helps, but it usually kills them. Frits Zernike found a way to make living, unstained cells stand out. This post covers his life, how he got there from a different corner of optics, worked examples on path difference, and what a student can take from his way of working.
Who was Frits Zernike?
His Nobel facts page gives his birth as 16 July 1888 in Amsterdam and his death on 10 March 1966 in Groningen. His Nobel biography says both parents taught mathematics, that as a schoolboy he made his own ether for photography experiments, and that he studied chemistry at Amsterdam from 1905. He became a lecturer in mathematical physics at Groningen in 1915 and a full professor in 1920. He won the 1953 Nobel Prize in Physics "for his demonstration of the phase contrast method, especially for his invention of the phase contrast microscope".
Why are living cells hard to see?
The award ceremony speech puts it simply: bacteria and cells are colourless and transparent, and staining is not always suitable, "for example when we are dealing with living objects". Light passing through a cell is not dimmed much. It is delayed, because the cell refracts slightly more strongly than the water around it. In Zernike's Nobel lecture, he explains that at exact focus this delayed light recombines to give the same brightness as the background, so the detail "remains invisible".
How did he find phase contrast?
Not with a microscope. In the lecture text he says it began with diffraction gratings. Tiny periodic errors in ruling the grooves produce faint extra spectral lines called Rowland ghosts. Around 1930 he noticed that stripes seen on a large grating vanished when a telescope was focused exactly on its surface, and worked out that the ghosts were 90 degrees out of phase with the main line.
To change that, he etched glass with very dilute hydrofluoric acid, a method Lord Rayleigh had described, making "phase-strips": glass plates with a groove "of a uniform depth of half a wavelength". Then he made the jump to the microscope, where Abbe's theory already treated a transparent object like a grating. With his phase plate the direct light was advanced by 90 degrees and the transparent detail appeared dark, as if "optically stained".
Worked example 1: why does a half-wavelength groove give 90 degrees?
Removing glass of depth d from a plate changes the optical path by (n − 1)d, where n is the refractive index. Take glass with n = 1.5 (a sample value) and green light, λ = 550 nm.
Groove depth. Half a wavelength: d = 550 / 2 = 275 nm.
Optical path change. (1.5 − 1) × 275 nm = 137.5 nm, which is λ/4.
Phase change. A path difference of λ corresponds to 2π, so λ/4 gives 2π/4 = π/2, or 90 degrees.
This uses the same rule as Young's double slit in the NCERT Wave Optics chapter, where a path difference of 2λ corresponds to a phase difference of 4π.
Worked example 2: how much does a cell delay light?
Sample numbers: a cell 5 micrometres thick with refractive index 1.36, in water with index 1.33.
Optical path difference. (1.36 − 1.33) × 5.0 µm = 0.15 µm.
In wavelengths. 0.15 / 0.55 = 0.27 of a wavelength.
Phase. 0.27 × 360° ≈ 98°, or about 1.7 radians.
That is a large phase shift but almost no change in brightness, which is exactly what the eye cannot detect and phase contrast can.
What mistakes do students make with path difference?
Using geometric thickness alone. Optical path is n times thickness; differences come from (n₁ − n₂)t.
Mixing degrees and radians. Write which one you are using at every step.
Using the wrong λ. Keep the vacuum wavelength with optical path, or wavelengths in a medium with geometric path, but not a mix.
Interference and path difference are in Unit 16 of the JEE (Main) 2026 syllabus; phase contrast itself is not, so check your year's syllabus. Our post on Young's double-slit problems gives more practice, and Leeuwenhoek's microbes shows how early microscopists coped without stain. If waves adding in and out of phase are hard to picture, the Fermi Simulation Lab has interactive simulations for ideas that are easier to see than read.
Why did it take so long to reach laboratories?
In the lecture Zernike recalls taking the method to the Zeiss works in Jena in 1932, where an older staff member told him: "If this had any practical value, we would ourselves have invented it long ago". Zeiss developed it slowly and released phase-contrast objectives in 1941.
What can a student take from how he worked?
Keep a puzzle in mind for years. He had noticed the grating stripes long before he could test them.
Carry ideas across fields. A grating problem solved a microscope problem.
Do not let one rejection decide. The method reached laboratories nine years after the Zeiss visit.
Next step: find the phase shift for a cell 3 µm thick with index 1.38 in water, in degrees and radians.
