Age pyramids appear as one small figure in the Organisms and Populations chapter, yet they test a skill students rarely practise: reading a graph and saying what it means. This post explains what the three shapes show, turns raw numbers into a pyramid with a worked example, uses real UN data for three countries, and ends with a practice routine.
Where are age pyramids in the syllabus?
The NEET (UG) 2026 syllabus lists "Population attributes-growth, birth rate and death rate, age distribution." The CBSE Biology curriculum for 2026-27 keeps the Organisms and Populations chapter in the Class 12 unit on Ecology and Environment, with age distribution named among population attributes. The text is section 11.1 of NCERT Class 12 Biology, Chapter 11. Check the syllabus for your own exam year.
Our post on organisms and populations covers growth models and birth and death rates. This one is only about age structure.
What is an age pyramid?
NCERT says a population at any time is made of individuals of different ages. If you plot the age distribution, meaning the per cent of individuals in each age or age group, the result is an age pyramid. For humans, the pyramid usually shows males and females on either side of a central line.
NCERT's Figure 11.1 splits the bars into three bands from bottom to top: pre-reproductive, reproductive and post-reproductive. The shape, NCERT says, reflects the growth status of the population.
What do the three shapes mean?
Expanding (growing): the pre-reproductive band at the base is the widest. Many young individuals will soon reach reproductive age, so numbers will rise.
Stable (stationary): the pre-reproductive and reproductive bands are about the same width. Each generation roughly replaces the one before.
Declining: the pre-reproductive band is narrower than the reproductive one. Fewer individuals will enter the reproductive years, so numbers will fall.
The key is to compare the base with the band just above it. The top of the pyramid tells you less about future growth, because post-reproductive individuals no longer add births.
Worked example: from counts to a shape
The numbers here are sample numbers for practice.
A survey of 1,000 deer in a sanctuary finds 450 pre-reproductive, 350 reproductive and 200 post-reproductive animals.
Pre-reproductive share: 450 / 1000 = 45%.
Reproductive share: 350 / 1000 = 35%.
Post-reproductive share: 200 / 1000 = 20%.
Check: 45 + 35 + 20 = 100%.
The base (45%) is wider than the band above it (35%), so the pyramid is expanding.
Now change the counts to 250, 450 and 300. The shares become 25%, 45% and 30%. The base is now narrower than the reproductive band, so the pyramid is declining, even though the total is still 1,000.
What do real human pyramids look like?
Demographers usually group people as children (under 15), working-age adults (15 to 64) and older people (65 and over). These bands are not the same as NCERT's reproductive bands, but they show the shape well. The figures below are from the UN World Population Prospects 2024, as charted by Our World in Data. We have converted the counts to percentages and rounded them.
Niger, 2023: about 47% under 15, 50% aged 15-64 and 3% aged 65 and over. A very wide base: expanding.
Japan, 2023: about 12% under 15, 59% aged 15-64 and 29% aged 65 and over. A narrow base and heavy top: declining.
India, 1975: about 41% under 15, 55% aged 15-64 and 4% aged 65 and over.
India, 2023: about 25% under 15, 68% aged 15-64 and 7% aged 65 and over.
Here is the arithmetic for India in 2023. The UN estimates are 360.3 million under 15, 978.2 million aged 15-64 and 99.5 million aged 65 and over, a total of 1,438.0 million. So the under-15 share is 360.3 / 1438.0 ≈ 0.251, or about 25%, and the 65-and-over share is 99.5 / 1438.0 ≈ 0.069, or about 7%.
India's base has narrowed a lot since 1975, while the working-age middle has grown. The pyramid is moving from the expanding shape towards the stable one.
Which mistakes cost marks?
Judging by the top. A wide top means many older people; it does not by itself show decline.
Mixing up density and structure. Population density is how many; an age pyramid is how they are spread across ages.
Using counts from populations of different sizes. Convert to percentages before comparing shapes.
Forgetting the sexes. Human pyramids usually show males and females separately.
Treating 15-64 as the reproductive band. It is a demographers' working-age group, a rough stand-in only.
A practice routine for age structure
Day 1: draw NCERT's three pyramids from memory and label the three bands.
Day 2: make up three sets of counts and classify each shape, showing percentages.
Day 3: open the UN-based chart, pick two countries and decide which shape each is closest to.
Day 4: write a four-line answer to "How does an age pyramid show whether a population is growing?" and time yourself.
If you find it easier to see a shape change than read about it, the Fermi Simulation Lab has interactive simulations for ideas that are easier to see than read.
Today, sketch India's 1975 and 2023 pyramids side by side using the percentages above.
