Electrolytic refining is one diagram and a few lines in your Class 10 book, and board questions on it are predictable: label the electrodes, name the electrolyte, say what anode mud is. The marks are lost by swapping the anode and cathode, or by not knowing why some impurities dissolve while others fall. This post explains both, works a short example, and adds a quantitative version for Class 12 students.
Where is this in the syllabus?
Section 3.4.6 of NCERT Class 10 Science Chapter 3, Metals and Non-metals (2026-27 reprint), covers refining of metals. The CBSE Class X Science syllabus for 2026-27 lists "Basic metallurgical processes" in Unit I, so this is examinable in the board exam.
For older students, the picture has changed. The current NCERT Class 12 Chemistry Part I has five units (Solutions, Electrochemistry, Chemical Kinetics, the d- and f-Block Elements, Coordination Compounds) and no separate metallurgy chapter. The JEE (Main) 2026 syllabus and the NEET (UG) 2026 syllabus do not list isolation of metals, but both list electrolytic cells, and the Class 12 Electrochemistry chapter still uses copper refining as its example of electrolysis. Check your own year's documents.
How is the cell set up?
NCERT's Figure 3.12 shows three parts:
Anode (connected to the positive terminal): the block of impure copper.
Cathode (connected to the negative terminal): a thin strip of pure copper.
Electrolyte: acidified copper sulphate solution, a solution of a salt of the same metal.
NCERT notes that copper, zinc, tin, nickel, silver and gold, among others, are refined this way.
What happens at each electrode?
When current passes, copper from the anode dissolves into the electrolyte, and an equivalent amount of pure copper deposits on the cathode. The Class 12 Electrochemistry chapter gives the half-reactions:
At the anode (oxidation): Cu(s) → Cu²⁺(aq) + 2e⁻
At the cathode (reduction): Cu²⁺(aq) + 2e⁻ → Cu(s)
So the anode gets thinner, the cathode gets thicker, and the copper ions in the solution act as a conveyor belt between them.
Where do the impurities go?
NCERT: "The soluble impurities go into the solution, whereas, the insoluble impurities settle down at the bottom of the anode and are known as anode mud."
Why does an impurity go one way or the other? Class 12 students can use the standard electrode potentials in NCERT's Table 2.1. Copper's is +0.34 V. Zinc (−0.76 V) and iron (−0.44 V) have lower values, so they are oxidised more easily than copper. They dissolve at the anode and stay in solution as ions, because Cu²⁺ is reduced at the cathode more easily than they are. Silver (+0.80 V) and gold (+1.40 V) have higher values, so they are not oxidised. As the copper around them dissolves, they drop off as anode mud. Class 10 students can reach the same answer for these metals from the reactivity series: zinc and iron sit above copper and dissolve; silver and gold sit below it and fall.
Worked example: predict the result
A block of impure copper contains small amounts of zinc, iron and silver. It is refined as above. Answer three questions.
Which electrode gains mass? The cathode, as pure copper deposits on it.
Where does each impurity end up? Zinc and iron dissolve and stay in the solution. Silver collects in the anode mud.
Why is the anode mud worth collecting? It holds the less reactive metals that did not dissolve, which here includes silver.
A Class 12 extension: how much copper?
Faraday's laws turn this into a calculation. NCERT gives the Faraday constant as 96,487 C per mole of electrons and uses 96,500 for approximate work. Take Cu = 63.5 g/mol.
A current of 5.00 A passes for 2.00 hours. What mass of copper deposits on the cathode?
Charge Q = It = 5.00 × 7200 = 36,000 C.
Moles of electrons = 36,000 ÷ 96,500 = 0.373 mol.
Two electrons per Cu²⁺, so moles of Cu = 0.373 ÷ 2 = 0.187 mol.
Mass = 0.187 × 63.5 ≈ 11.8 g.
Going backwards, depositing 100 g of copper at 10.0 A needs (100 ÷ 63.5) × 2 × 96,500 ≈ 304,000 C, which takes about 30,400 s, or roughly 8.4 hours. For more calculations of this kind, see our post on electrolysis and Faraday's laws.
Which mistakes cost the most marks?
Swapping the electrodes. Impure copper is the anode; pure copper is the cathode.
Naming the wrong electrolyte. It is acidified copper sulphate, a salt of the metal being refined.
Putting anode mud at the cathode. It settles below the anode.
Saying all impurities form anode mud. Soluble ones stay in solution.
Mixing up refining with extraction. Refining purifies a metal that has already been extracted.
A practice routine
Draw Figure 3.12 from memory, labelling anode, cathode, electrolyte and anode mud, then check.
Write both half-reactions and say which is oxidation.
Sort four metals (Zn, Fe, Ag, Au) into "dissolves" or "anode mud" and give the reason for each.
Class 12 only: two Faraday sums, one forwards and one backwards.
For the reactivity series behind step 3, see our guide to metals and non-metals for Class 10. If one idea will not stick, the Fermi Concept Library covers every concept in chemistry, each with its own lesson.
Tonight, draw the refining cell from memory and write one sentence explaining why silver ends up in the anode mud.
